Sawtooth Wave
signal-synthesis · 37 views
signal-synthesisperiodic
What It Is
Sawtooth wave --- linear ramp with discontinuous reset, rich in harmonics (1/n Fourier decay)
Interpretation
Standard analysis sees: rich, high-entropy values; long-range memory (persistent); strongly periodic; low-complexity (predictable, not noise-like); time-irreversible (slow rise, sharp collapse); volatility-clustering (bursty); low-dimensional. The atlas additionally detects Time Reversibility:ordinal_reversal_distance. It sits beside Rossler Attractor in the atlas (standard-bank rank 35) — a neighbor conventional features miss.
What standard analysis sees
tail heaviness0.28
asymmetry0.38
occupancy0.98
short-range corr0.77
long-range memory0.92
spectral colour0.40
periodicity0.89
complexity0.00
time-irreversibility0.00
volatility clustering0.98
multifractality0.76
dimensionality0.09
nonstationarity0.40
What the atlas adds
Time Reversibility:ordinal_reversal_distance+3.0z
time-reversal symmetry breaking via Bandt-Pompe ordinal patterns
Atlas-extreme metrics the standard bank can’t predict for this source
Symplectic:flux_sign_persistence | +5.3z | bank-miss 2.2σ |
Wavelet Cascade:intermittency_slope | -3.6z | bank-miss 1.6σ |
Multifractal Spectrum:spectrum_width | +3.4z | bank-miss 2.5σ |
WaveformAsymmetry:waveform_asymmetry | +3.3z | bank-miss 1.9σ |
Laplacian:laplacian_evolutionary_index | +3.1z | bank-miss 3.5σ |
Higher-Order Statistics:kurt_max | +3.0z | bank-miss 1.4σ |
Laplacian:gradient_curvature_anticorrelation | +2.4z | bank-miss 2.6σ |
