Pulse-Width Modulation

signal-synthesis · 37 views
signal-synthesisperiodic

What It Is

Pulse-width modulation --- binary carrier (0/255) whose duty cycle sweeps smoothly via sine modulation, encoding an analog signal in digital on/off timing

Interpretation

Standard analysis sees: bounded / light-tailed; few distinct values; low-complexity (predictable, not noise-like); multifractal. The atlas finds no named structure, but the source is distinctively extreme on E8 Lattice:coset_transition (+4.7z) — beyond what the standard bank predicts for it.

What standard analysis sees
tail heaviness0.03
asymmetry0.21
occupancy0.06
short-range corr0.70
long-range memory0.75
spectral colour0.43
periodicity0.71
complexity0.02
time-irreversibility0.25
volatility clustering0.72
multifractality0.97
dimensionality0.44
nonstationarity0.66
What the atlas adds
Atlas-extreme metrics the standard bank can’t predict for this source
E8 Lattice:coset_transition+4.7zbank-miss 2.3σ
S² × ℝ (Thurston):height_drift-4.4zbank-miss 2.1σ
G2 Root System:pair_angle_kurtosis+3.3zbank-miss 1.5σ
Wavelet Cascade:scale_gini_dispersion+3.1zbank-miss 1.7σ
Visibility Graph:avg_clustering_coeff-3.0zbank-miss 1.5σ
Mostow Rigidity:margulis_ratio+3.0zbank-miss 1.7σ
Modular Residue:occupancy_entropy-2.3zbank-miss 1.7σ
Septagonal (Danzer):z_primary+2.1zbank-miss 1.5σ

Composition

dtypefloat64
range[0, 1]
unique values2 / 16384
mean ± std0.474 ± 0.499

Binary sequence — two distinct symbols.
