IMS Bearing Degraded
machine-vibration · 37 views
machine-vibrationperiodic
What It Is
NASA IMS test 2, day 6 snapshot, bearing 1. Same rig as healthy but mid-degradation; outer-race spalling has begun, periodic impulse component starts to emerge above the broadband floor.
Interpretation
Standard analysis sees: no strongly notable standard properties. The atlas detects no named structure beyond this. It sits beside MFPT Normal in the atlas (standard-bank rank 29) — a neighbor conventional features miss.
What standard analysis sees
tail heaviness0.75
asymmetry0.30
occupancy0.43
short-range corr0.49
long-range memory0.32
spectral colour0.54
periodicity0.57
complexity0.60
time-irreversibility0.81
volatility clustering0.47
multifractality0.35
dimensionality0.75
nonstationarity0.49
What the atlas adds
Nothing beyond the standard reading — this source’s structure is already captured by standard features; the atlas adds no named residual.
Composition
dtypefloat64
range[-0.454, 0.498]
unique values323 / 16384
mean ± std-0.00176 ± 0.105
