What It Is
CWRU bearing vibration, outer-race fault. Drive-end accelerometer at 48 kHz; cleaner impulse train than inner-race because the defect is stationary in the load zone.
Interpretation
Standard analysis sees: anti-persistent; red spectrum (low-frequency / 1-over-f power). The atlas finds no named structure, but the source is distinctively extreme on Septagonal (Danzer):z_primary (+3.8z) — beyond what the standard bank predicts for it. It sits beside Bearing Inner in the atlas (standard-bank rank 22) — a neighbor conventional features miss.
What standard analysis sees
tail heaviness0.64
asymmetry0.55
occupancy0.54
short-range corr0.66
long-range memory0.12
spectral colour0.04
periodicity0.49
complexity0.29
time-irreversibility0.65
volatility clustering0.64
multifractality0.57
dimensionality0.71
nonstationarity0.62
What the atlas adds
Atlas-extreme metrics the standard bank can’t predict for this source
Septagonal (Danzer):z_primary | +3.8z | bank-miss 1.8σ |
AutoRegressive:ar_coef_2 | -3.6z | bank-miss 1.1σ |
Continued Fraction:log_khintchine_mean | +3.1z | bank-miss 2.1σ |
Composition
dtypefloat64
range[-0.5067, 0.5226]
unique values3098 / 16384
mean ± std0.00898 ± 0.139
