What It Is
CWRU bearing vibration, inner-race fault. Drive-end accelerometer at 48 kHz; periodic impulses ride a broadband resonance.
Interpretation
Standard analysis sees: heavy-tailed; anti-persistent; red spectrum (low-frequency / 1-over-f power); nonstationary / drifting. The atlas finds no named structure, but the source is distinctively extreme on Continued Fraction:log_khintchine_mean (+3.3z) — beyond what the standard bank predicts for it.
What standard analysis sees
tail heaviness0.92
asymmetry0.65
occupancy0.35
short-range corr0.68
long-range memory0.12
spectral colour0.04
periodicity0.55
complexity0.28
time-irreversibility0.19
volatility clustering0.70
multifractality0.74
dimensionality0.58
nonstationarity0.93
What the atlas adds
Atlas-extreme metrics the standard bank can’t predict for this source
Continued Fraction:log_khintchine_mean | +3.3z | bank-miss 1.7σ |
Septagonal (Danzer):z_primary | +3.2z | bank-miss 1.0σ |
Spirograph:petal_symmetry | +3.0z | bank-miss 1.4σ |
Composition
dtypefloat64
range[-2.141, 2.392]
unique values2690 / 16384
mean ± std0.0149 ± 0.277
