Bearing Ball
machine-vibration · 37 views
machine-vibrationperiodic
What It Is
CWRU bearing vibration, ball fault. Drive-end accelerometer at 48 kHz with a 0.014 in diameter ball-element defect.
Interpretation
Standard analysis sees: red spectrum (low-frequency / 1-over-f power). The atlas finds no named structure, but the source is distinctively extreme on AutoRegressive:ar_coef_2 (-5.5z) — beyond what the standard bank predicts for it. It sits beside EEG Seizure in the atlas (standard-bank rank 28) — a neighbor conventional features miss.
What standard analysis sees
tail heaviness0.82
asymmetry0.66
occupancy0.39
short-range corr0.67
long-range memory0.19
spectral colour0.03
periodicity0.56
complexity0.31
time-irreversibility0.40
volatility clustering0.67
multifractality0.67
dimensionality0.72
nonstationarity0.83
What the atlas adds
Atlas-extreme metrics the standard bank can’t predict for this source
AutoRegressive:ar_coef_2 | -5.5z | bank-miss 1.5σ |
Continued Fraction:log_khintchine_mean | +3.1z | bank-miss 1.9σ |
AutoRegressive:ar_coef_1 | +2.7z | bank-miss 1.3σ |
Septagonal (Danzer):z_primary | +2.5z | bank-miss 1.5σ |
Composition
dtypefloat64
range[-1.293, 1.83]
unique values3080 / 16384
mean ± std0.0117 ± 0.153
