MFPT Outer Race
machine-vibration · 37 views
machine-vibrationperiodic
What It Is
MFPT bearing vibration, outer-race fault. 97.656 kHz, 270 lb load; matches CWRU outer-race fault topology but at a higher sample-rate and lower RPM (25 Hz shaft / 1500 RPM vs CWRU ~1772), on a different bearing model.
Interpretation
Standard analysis sees: no strongly notable standard properties. The atlas detects no named structure beyond this.
What standard analysis sees
tail heaviness0.65
asymmetry0.28
occupancy0.46
short-range corr0.46
long-range memory0.27
spectral colour0.56
periodicity0.35
complexity0.82
time-irreversibility0.65
volatility clustering0.40
multifractality0.43
dimensionality0.81
nonstationarity0.45
What the atlas adds
Nothing beyond the standard reading — this source’s structure is already captured by standard features; the atlas adds no named residual.
Composition
dtypefloat64
range[-2.85, 2.751]
unique values15760 / 16384
mean ± std-0.113 ± 0.703
