Exponential Chirp

signal-synthesis · 37 views
signal-synthesisperiodic

What It Is

Exponential frequency sweep --- instantaneous frequency grows geometrically, creating equal time per octave. Used in acoustic measurements and radar

Interpretation

Standard analysis sees: bounded / light-tailed; smooth / autocorrelated; long-range memory (persistent); red spectrum (low-frequency / 1-over-f power); low-complexity (predictable, not noise-like); volatility-clustering (bursty). The atlas finds no named structure, but the source is distinctively extreme on Nonstationarity:variance_trend (+6.9z) — beyond what the standard bank predicts for it. It sits beside Chua's Circuit in the atlas (standard-bank rank 24) — a neighbor conventional features miss.

What standard analysis sees
tail heaviness0.10
asymmetry0.19
occupancy0.81
short-range corr0.95
long-range memory0.95
spectral colour0.11
periodicity0.56
complexity0.05
time-irreversibility0.73
volatility clustering0.93
multifractality0.81
dimensionality0.17
nonstationarity0.80
