Triangle Wave
signal-synthesis · 37 views
signal-synthesisperiodic
What It Is
Triangle wave --- linear ramps up and down, smooth peaks with 1/n² Fourier decay (only odd harmonics)
Interpretation
Standard analysis sees: rich, high-entropy values; red spectrum (low-frequency / 1-over-f power); strongly periodic; low-complexity (predictable, not noise-like); low-dimensional; stationary. The atlas additionally detects Multi-Scale Wasserstein:w_max_ratio, Persistent Homology:max_h1_lifetime.
What standard analysis sees
tail heaviness0.26
asymmetry0.46
occupancy0.89
short-range corr0.78
long-range memory0.42
spectral colour0.08
periodicity0.96
complexity0.14
time-irreversibility0.53
volatility clustering0.76
multifractality0.37
dimensionality0.12
nonstationarity0.06
What the atlas adds
Multi-Scale Wasserstein:w_max_ratio+5.4z
scale-coherent dispersion mismatch (max/min Wasserstein across scales)
Persistent Homology:max_h1_lifetime+5.2z
reconstructed phase space contains a persistent topological loop (S¹) — a smooth simple limit cycle
Atlas-extreme metrics the standard bank can’t predict for this source
Zipf–Mandelbrot (8-bit):zipf_r_squared | -3.6z | bank-miss 1.3σ |
Nonstationarity:dynamic_coupling | +2.6z | bank-miss 1.6σ |
Attractor Reconstruction:kaplan_yorke_dim | -2.2z | bank-miss 1.3σ |
Composition
dtypefloat64
range[-1, 1]
unique values16384 / 16384
mean ± std0.00145 ± 0.577
